Plot the causal graph of a ResitResult with ggplot2

Draws the estimated causal structure as a ggplot2-based directed graph, like autoplot.LingamResult(). Because RESIT returns 0/1 edge indicators rather than coefficients, edge labels are hidden by default (label_edges = FALSE); a constant "1" on every edge carries no information.

Usage

# S3 method for class 'ResitResult'
autoplot(
  object,
  threshold = 0,
  node_size = 16,
  node_color = "lightblue",
  label_edges = FALSE,
  label_pos = 0.35,
  ...
)

Arguments

object

Return value of lingam_resit() (a ResitResult object)

threshold

Coefficients with an absolute value at or below this are not treated as edges (default: 0)

node_size

Node size (default: 16)

node_color

Node fill color (default: "lightblue")

label_edges

Whether to display edge labels (default: FALSE, since every edge would be labeled "1")

label_pos

Position of each coefficient label along its edge, as a fraction from the source (0) to the target (1). The default 0.35 places labels off-center (toward the source) so labels on crossing edges do not overlap near the midpoint.

...

Unused

Value

A ggplot object

Examples

# \donttest{
if (requireNamespace("ggplot2", quietly = TRUE) &&
    requireNamespace("igraph", quietly = TRUE) &&
    requireNamespace("mgcv", quietly = TRUE)) {
  library(ggplot2)
  nonlinear <- generate_resit_sample(n = 300, seed = 1)
  model <- lingam_resit(nonlinear$data)
  autoplot(model)
}

# }
